7 Refuelling the Lawn Mower

► Press control bar for mowing (12) to handle‐
bar (13) and hold.
► Slowly pull starter handle (14) in the direction
of starter rope guide (15).
► Hook starter handle (14) into starter rope
guide (15).
► Release control bar for mowing (12).
► Re-attach the spark plug socket.
6.2 Adding Engine Oil
The engine oil lubricates and cools the engine.
The engine oil specification and capacity can be
found in the engine instruction manual.
NOTICE
■ The lawn mower does not contain any engine
oil on delivery. Starting the engine with no or
too little engine oil may damage the lawn
mower.
► Always check the engine oil level before
starting and if necessary top up.
► Add the engine oil as described in the engine
instruction manual.
7 Refuelling the Lawn Mower
7.1 Refuelling the Lawn Mower
NOTICE
■ The lawn mower may be damaged if the cor‐
rect fuel is not used.
► See the engine instruction manual.
► Stop the engine.
► Place the lawn mower on a level surface.
► Clean the area around the fuel tank cap with a
damp cloth.
0478-111-9656-A
► Turn fuel tank cap (1) anti-clockwise until it
can be removed.
► Remove the fuel tank cap.
► Add fuel using a suitable funnel, stopping at
least 15 mm short of the fuel tank brim.
► Place the fuel tank cap on the fuel tank.
► Turn the fuel tank cap clockwise and tighten
firmly by hand.
The fuel tank is sealed.
8 Adjusting the Lawn Mower
for the User
8.1 Folding Up and Adjusting the
Handlebar
► Stop the engine.
► Detach the spark plug socket.
► Place the lawn mower on a level surface.
► Loosen quick-clamping devices (1) on the left
and right.
► Fold up handlebar (2), ensuring that cables (3)
are not trapped.
► Tighten quick-clamping devices (1) on the left
and right.
Handlebar (2) is firmly attached to the lawn
mower.
