Check and adjust the Protection
Corners (4x) indicated on the
enclosure cover.
The SIM plug should be carefully
screwed back in place by hand to en-
sure no cross threading has occurred!
The plug should be screwed back in
place until fully engaged.
Important note: A minimum of 5 full
threads must be engaged to comply
with Ex safety regulations!
If required rotate the "SIM-Plug"
slightly back until the depression of
the plug is in the correct position to
be secured by the Safety Screw, as
shown on the picture to the right.
Use the Torque screwdriver set to 0.45
Nm to screw fix the Safety Screw in
place.
