3. SIM-Card Installation and Replacement instructions

3.1 Dissassembly

Turn the device to face the rear side
(display face down).
Unscrew the 13 Rear Cover screws
indicated anticlockwise using a Torx
screwdriver size 10.
Keep and store the screws for reas-
sembly as it is only allowed to use
the original screws supplied by ecom
instruments.
When all 13 rear cover screws have
been removed the backside cover can
be detached from the main device.
Store the backside cover safely to
ensure that it will not be damaged.
Unscrew the safety screw indicated
anticlockwise using a Torx
screwdriver size 10.
Keep and store the bolt.
