26 | English
Robotic Mower
Frequency
Output DC
Degree of protection
Weight
*depends on cutting height, grass conditions and moisture
**protected against splashing water from all directions
The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your garden
product. The trade names of the individual garden products may vary.

Noise/Vibration Information

Measured sound values determined according to EN 60335.
Typically the A-weighted noise levels of the product are:
Sound pressure level 64 dB(A); sound power level 72 dB(A).
Uncertainty K =2.74 dB.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under "Technical Data" is in conformity with the fol-
lowing standards or standardization documents: EN 60335
(battery powered product) and EN 60335 (battery charger)
according to the provisions of the directives 2011/65/EU,
2006/95/EC, 2004/108/EC, 2006/42/EC, 2000/14/EC.
2000/14/EC: Guaranteed sound power level 75 dB(A). Con-
formity assessment procedure according to Annex VI.
Equipment category: 32
Notified body:
SRL, Sudbury, England, Nr. 1088
Technical file (2006/42/EC, 2000/14/EC) at:
Bosch Lawn and Garden Ltd., PT-LG/ENS,
Stowmarket, Suffolk IP14 1EY, England
Dr. Egbert Schneider
Senior Vice President
Engineering
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
12.10.2012
Explanation of Installation Guide
(see pages 3–11)
Action
Delivery scope/unpacking product
Position the docking station
Thread wire through base plate
F 016 L70 825 | (23.11.12)
Indego
Hz 50/60
V
IP44**
kg
Helmut Heinzelmann
Head of Product Certification
PT/ETM9
Figure
1
2 – 3
4
Action
Connect first end of perimeter wire
42 Fix docking station to the ground
Lay out perimeter wire
2.0 Connect second end of perimeter wire
Clip on protective cover of docking station
Install power supply
Docking station indicates power on
Plug in isolator key
Charge battery by putting the machine into dock-
ing station
Welcome screen = Refer to manual
Lift up and carry the machine
Set height of cut
Cleaning
Maintenance
Lawn Preparation
Remove stones, loose pieces of wood, wire, live mains cables
and other foreign objects from the cutting area.
Make sure that the cutting area is even and has no ditches,
grooves and steep slopes above 20° that are clear obstruc-
tions for the machine.
Cut the main area of the lawn with a conventional mower to a
max. height of 40 mm and the perimeter wire area to a max.
height of 20 mm.
Installation
For a video guide on how to install the Indego please visit
www.bosch-indego.com or use the following QR-Code.
Select a position for the docking station, horizontally leveled
and out of direct sun light.
Make sure that the docking station is placed by the side of the
cutting area with a straight 2 m track in front and behind.
Whilst stood in the grass area to be cut it is important that the
docking station charging pins point to the left. (see figure 2)
Note - If the docking station is positioned with the charging
pins pointing either into the grass area or pointing to the right
the Indego will not leave the dock.
Pull the wire end through the front hole of the base plate and
straight through the wire duct and the rear hole. Fix the wire
with a peg inline with the hole. Cut off insulation carefully and
Figure
5
6
7
8
9
10
11
12
13
14
15
16
A
B
