If it is in chalk line, hold the head and rotate the top cover (12) so that
the beam comes out of the beam aperture (3). To put laser on scan mode,
use keypad, detector, or remote.
1. To scan, simultaneously press (14) and (17). The beam will blink
until it has self-leveled, and then will start scanning.
2. Use (14) or (15) to aim the scan.
3. Use the bottom two keys to adjust the scanning length. Use (17)
to increase and (18) to decrease (3° to 34°).
4. To turn the scanning off, simultaneously press (14) and (17) again.
The square shot cannot be moved left or right when scanning; laser
must be in point or chalk line mode.

2.9 Manual slope

1. After turning the laser on and allowing it to self-level, press the
Auto/Man key (20). The LED next to it (19) will blink, indicating you
are in manual mode and you can set slope in the X axis. The head
will start rotating.
2. Press (17) to set a positive slope in X and press (16) to set a
negative slope.
3. To switch to the Y axis, press the Tilt key (22). Both LEDs (19) and
(21) will blink, indicating that you are in manual mode and that you
can set slope in Y axis.
4. Press (17) to set a positive slope in Y and (16) to set a negative
slope.

3.0 Power

3.0.1 Installing alkaline batteries
1. To install alkaline batteries in your SKR301 laser, unscrew the
b a t t e ry cap located at the bottom of the instrument.
2. Remove the battery pack.
3. Insert two alkaline batteries (D or LR20) in the pack, matching the
polarity ("+" or "–") as indicated at the bottom of the pack.
4. Put the battery back into its place and tighten the screw. Yo u r
A 410 is ready for use.
To replace batteries
1. When battery power is low, the laser head will stop rotating, and
the low battery light (23) will come on.
2. Replace both batteries at the same time.
8

3.0.2 Using rechargeable batteries

First-time use
If your SKR301 is equipped with rechargeable battery, you must
recharge it for 15 hours before first use.
1. Insert the recharger jack plug into the jack located on the battery
pack (10).
2. Plug the charger into an electrical outlet (110 volts or 220 volts,
depending on charger and country).
3. Charge for 15 hours.
Always recycle
s
batterie
Later recharges
The SKR301 can be charged while working. If electricity is available
on the job site, simply plug in the charger and keep on working. You
can also remove the battery pack to charge it, and replace with the
alkaline battery compartment to keep on working.
For optimum life of the battery, it is recommended to only charge the
battery after it has been fully discharged.
To ensure battery life, do not charge over 20 hours. The battery and
the charger can be damaged if damp. Always store and charge your
instrument in a dry and covered place.

3. Checking and adjusting your SKR301

THIS CHAPTER IS VERY IMPORTA N T: Here are a few simple
instructions to check your SKR301 for calibration.
Remember that the laser is a precision instrument and that it is
i m p o rtant that you keep it calibrated and in proper condition. The
accuracy of your work is completely your responsibility and you
should regularly check your instrument especially prior to import a n t
jobs. Before any checking on calibration ensure laser is in point
mode when rotation stopped. Directions follow for checking each
axis for calibration. If the laser needs to be calibrated, follow the
instructions or take it to a service centre.
Do not discard batteries
into garbage can or the
like
9
