Product Specifications

2 Product Specifications
2.1

Function

EN
The NVOR-200 interface transmits a signal between the smoke detector and the warning
device. If an alarm is set off by the smoke detector, this signal is converted in the interface.
LEDs on the warning device indicate the alarm and an acoustic signal also sounds.
2.2

Dimensions and design

1
2
2.3

Product program

Warning device
Description
Intrinsically safe warning device, 230 V AC
Sensor
Description
Smoke detector, for detecting smoke
Accessories
Description
Interface between warning device and sensors
6 - EN
1
68301 Mannheim Germany
www.pepperl-fuchs.com
Resistance Unit
2
Reset
NVOR-200
[Ex ia] IIB
DEMKO 07 ATEX 142591
II (1) G
0102
36
Connection of sensor circuit
Reset button
56
19
29 10
58
Type code
NVO5-11
Type code
ST-I-IS
Type code
NVOR-200
