Faller 161668 Handbuch Seite 4

4
Rectifier 3000 mA
General:
Description
The rectifier permits several FALLER car-system components to be connected and supplied with DC voltage at the same time.
If connected to a transformer, e.g., FALLER Art.No. 180641, the rectifier can be loaded with 3000 mA for a short period of time (5 to 10 minutes).
IMPORTANT:
CAUTION:
Design basis
for different components related to continuous current of
Dependent on the power requirements of the individual components, the following items can be connected:
Stop point
Branch, electrical
Branch
Parking lot, electrical
1 Magnet enable coil
The possible current loading is always dependent on the type of transformer used.
Please consult the technical DATA, if you use a transformer other than the above one.
If 16 V / 1 A (1000 mA), e.g., is specified on the transformer, a current loading of only
1 A (1000 mA) will be possible on the rectifier.
Continuous current loading 2500 mA max.
There is a risk of overheating.
To be observed by all means:
Use wires with a large cross-sectional area for the feed lines from the transformer to the rectifier.
The conductor cross-sectional area should be
If the wires are too thin, this does not only mean excessive heating of the feed lines, but also
DC voltage losses of more than 2 VDC.
Mount the rectifier with a clearance of
Caution in the event of short-circuit.
The recitifier does not have any overload protection.
Art. No. 161675 approx. 138 mA
Art. No. 161677 approx. 138 mA
Art. No. 161676 approx. 520 mA
Art.-No. 161674 approx. 310 mA
Art. No. 16168 .. approx. 310 mA
1 - 1.5 mm 2 min.
at least 5 cm, so that good air circulation is possible.
2500 mA
max. 18 pcs.,
max. 18 pcs,
max. 4 pcs.,
max. 8 pcs.,
max. 8 pcs.
or
or
or
or
