Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended use
Transportable diamond drill GDB 180 WE + GCR 180
Diamond drill
In conjunction with diamond wet-drilling core bits and a wa-
ter supply, the power tool is intended for wet drilling in con-
crete and reinforced concrete. The power tool can be com-
bined with a dust extraction attachment (water collection
ring and wet/dry extractor).
In conjunction with dry diamond core bits and a suitable dust
extraction attachment, the power tool is intended for dry
drilling in brick, sandstone, aerated concrete and tiles.
When used in a fixed position, the power tool must be held in
place by the drill stand for diamond drills GCR 180. Over-
head work is not permitted.
Drill stand for diamond drills
The drill stand for diamond drills is intended for mounting
the Bosch diamond drill GDB 180 WE. Other tools may not
be used.
The drill stand for diamond drills can be secured to the floor
or the wall using an anchor.
The drill stand for diamond drills can be attached to the floor
by means of vacuum (accessory) or (with an additional safe-
guard) against the wall. Attaching overhead is not permitted.
Product features
The numbering of the product features refers to the repres-
entation of the power tool and drill stand on the graphic
pages.
Diamond drill
(1) On/off switch
(2) Lock-on button for on/off switch
(3) Level for vertical alignment
(4) Level for horizontal alignment
(5) Gear selector switch
(6) Claw coupling
(7) Drill spindle
A)
(8) Core bit
(9) Handle (insulated gripping surface)
(10) Water cutoff valve
(11) Valve adapter
(12) Water connection adapter
(13) Extraction adapter
Bosch Power Tools
A)
(14) Extraction outlet
A)
(15) Extraction hose
(16) Portable residual current device (PRCD)
A) Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
Drill stand for diamond drills
(17) Star handle (insulated gripping surface)
(18) Screw on the drill holder
(19) Drill holder
(20) Drill column
(21) Upper screw of the drilling angle adjuster
(22) Levelling screw
A)
(23) Water collection ring
(24) Lower screw of the drilling angle adjuster
(25) Base plate
(26) Rack
(27) Clamping nut of the drilling angle adjuster
(28) Feed pinion
(29) Locking brake
(30) Masonry anchor/concrete anchor
A)
(31) Quick-clamping spindle
(32) Wing nut for the quick-clamping spindle
(33) Tension spring for the water collection ring
(34) Sliding guides
(35) Hex nut for sliding guides (x 10)
(36) Threaded pin for sliding guides (x 10)
A) Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
Technical data
Transportable diamond drill GDB 180 WE + GCR 180
Diamond drill
Article number
Rated power input
Power output
Rated speed n
0
– First gear
– Second gear
Drilling diameter
– optimum in masonry
– possible in masonry
– optimum in concrete
– possible in concrete
Tool holder
Max. pressure of water supply
English | 17
A)
A)
A)
GDB 180 WE
3 601 A89 8..
W 2000
W 1340
−1
min 900
−1
min 2800
mm 40–180
mm 0–180
mm 40–150
mm 0–180
1 1/4" UNC
bar 3
