Velleman CAMCOLVC6 Bedienungsanleitung Seite 7

(folder containing AVI video files). Open the video files using
®
Windows Media Player.
Adjusting the wristband
Refer to the illustration on page 3 of this manual.
• First determine the appropriate size of the wristband. Count how
many links should be removed.
• [1] Use a small screwdriver to push the protrusion on the link next
to the clasp down and away from the wristband (see arrow on
image).
• [2] Pull out the pin completely.
• [3] Slide the link over the connection plate.
• Count the number of links to be removed and repeat the above
procedure [1-3].
Note: it is better to remove e.g. 2 links on either side of the clasp than
4 links on one side and none on the other.
• Hook the last link back over the connection plate.
• Re-insert the pin. Make sure it does not stick out of the wristband.
• Small changes in wristband size can be achieved by moving the
clasp itself. Use a small object (e.g. an unfolded paperclip) to gently
press on the flanged spring bar. Re-insert the spring bar on one side
into the desired location, press the flange on the other side of the
bar down and move the wristband until the spring bar snaps into
place. Make sure the spring bar is in the same position on both
ends.
• To remove/replace the entire wristband, use a small screwdriver to
push down the flanges of the spring bars that are mounted between
the lugs at both sides of the watch.
7. Batteries
• This camera/watch contains an internal rechargeable battery.
When the device is end-of-life, this battery has to be removed.
• To do this, open the back cover.
• Cut off the battery leads and dispose of the battery in accordance
with local regulations.
WARNING: Never dispose of batteries in fire, as they
could explode. Keep batteries away from children.
CAMCOLVC6
7
Rev. 01
©Velleman nv
