Velleman CAMCOLVC6 Bedienungsanleitung Seite 5

4. Features
• for audio and video recording
• 2GB integrated flash memory
• two pushers
• USB 2.0 plug and play device
• USB cable included
5. Overview
Refer to the illustration on pages 2 and 3 of this manual.
A camera lens
B crown
C status LED
D camera on pusher
E USB connection port
6. Setting/operation
Refer to the illustration on pages 2 and 3 of this manual.
Battery charging
• Open the cover of the USB port [E] and plug the jack of the
included USB cable in the watch connection. Plug the USB connector
into a USB port of the PC.
Note: Never connect the watch to the PC in reverse order! If you do, it
may seriously damage the watch and the PC. To disconnect the
watch from the PC, first click onto the icon (
hardware) at the bottom of your screen and select Eject USB-
disk. Disconnect the watch from the PC only after the message
You can now safely remove hardware has appeared to
prevent damage to the watch and the PC.
• The status LED [C] turns green.
Using the wristband
• To open the wristband, first lift the clasp protection [H].
• Push both clasp locks [J] simultaneously and pull the clasp [I]
upward.
• To close, firmly press the clasp [I] until it snaps into place and
close the clasp protection [H].
Setting the date
• Simply pull the crown [B] away from the housing (±1mm) and
rotate until the hands show the correct time.
CAMCOLVC6
F camera off/ reset pusher
G microphone
H clasp protection
I clasp
J clasp lock (2x)
5
Rev. 01
Safely remove
©Velleman nv
