Cleaning the Turbo Brush
1. To thoroughly clean the turbo brush it can be disassembled.
2. First grasp the catches at the left and right side of the housing and gently and
very carefully pull out the caches. Than press with your finger the brushing
roller in the opposite direction. Now the turbo brush is disassembled and the
housing can be removed.
3. Remove long hair or other large dirt particles from the brushing roller.
4. Reassemble the turbo brush and make sure the catches engage into place
into the holding pins of the housing.
Replacing the drive belt of the Turbo Brush
1. If the drive belt has to be replaces, carefully lift
up the brushing roller from the notches and
replace the drive belt.
2. Insert the new drive belt as shown in the figure
and make sure the toothed side of the belt is
facing inwards.
The article no. for the drive belt is 91 57 140.
