Operation

6 Operation
6.1

Device operation

•
Attach the device (RG-8/40) to the carrier/hoist using the suspension eye.
•
Adjust the opening width/gripping range and height-adjustable support according to the material to be gripped
(concrete pipe).
•
Position the implement (RG-8/40) above the material to be gripped and lower it until the support rests on it.
•
As soon as the implement is completely lowered, the automatic changeover unlocks and closes during the subsequent
lifting.
•
Transport the material to be gripped (concrete pipe) to the determination position.
•
Lower the implement (RG-8/40). The automatic change-over switches to locking when the load is relieved, whereby
the device can be lifted again.
Goods to be gripped (concrete pipes) must always be gripped below the largest pipe diameter.
Otherwise there is a danger of slipping! DANGER TO LIFE!!! 
•
54500004 13 / 19 GB
