Intended purpose

The cordless chainsaw is constructed for
sawing wood only. The saw is not de-
signed for any other types of application
(e.g. cutting of brickwork, plastic or food).
The device is part of the Parkside
X 20 V TEAM series and can be oper-
ated using Parkside X 20 V TEAM series
batteries. The batteries may only be
charged using chargers from the Parkside
X 20 V TEAM series.
The chainsaw is designed for employment
in the do-it-yourselfer sector. It was not
designed for continuous employment in the
commercial sector.
The device is designed for use by adults.
Young people over 16 years old may use
the chainsaw under supervision only.
The manufacturer is not liable for dam-
ages, which were caused through use in
applications for which it was not designed,
or incorrect operation.
This electric chainsaw is to be used only
by one person and only for sawing wood.
The chainsaw must be held with the right
hand on the rear handle and the left hand
on the front handle. Before use, the user
must have read and understood all of the
information and directions in the operating
instructions. The user must wear appropri-
ate personal protective equipment (PPE).
The chainsaw is to be used only for sawing
wood. Materials such as plastic, stone,
metal or wood containing foreign objects
(e.g. nails or screws) must not be cut with
the chain saw!

General description

The illustration of the principal
functionin g parts can be
found on the front and back
foldout pages.
34

Extent of the delivery

Carefully unpack the appliance and check
that it is complete:
• Cordless chainsaw
• Chain bar (guide rail) (already
mounted)
• Saw chain (already mounted)
• Saw bar protection sheath
• Oil bottle with 180 ml bio chain oil
• Instruction Manual
The rechargeable batteries and the
charger are not included in delivery.
Dispose of the packaging material cor-
rectly.

Function description

The cordless chainsaw is equipped with
a chain quick-tensioning system. The
circulating saw chain is guided over a
blade (guide rail). An automatic oil system
ensures continuous chain lubrication. The
device is provided with various protective
devices to protect the user.
Refer to the following descriptions for the
function of control elements.

Overview

1 Rear handle
2 On/Off switch
3 Switch lock
4 Oil tank cover
5 Front handle
6 Chain brake lever/front hand
protection
7 Saw chain
8 Blade (guide rail)
9 Chain catch
10 Mounting screw for the sprocket
cover
