Viscount Vivace 90 - 90 Deluxe

2.4 PEDAL BOARD CONTROLS

The bottom part of the organ, above the pedal board, contains the swell pedals and a number of foot
pistons for controlling the couplers, the general combinations (Vivace 90 Deluxe), the Plenum and Reed
functions (Vivace 90) and the Tutti.
VIVACE 90 Deluxe
II / P
III / P
1. Pistoni a piede delle unioni: questi pistoni attivano le unioni dell'organo descritte nel par. 2.1 (punti
1 e 2).
2. [CRESCENDO] pedal: you can use this pedal to select the Crescendo steps which activate a preset
series of stops. The step currently selected is displayed by the [CRESCENDO] LED bar on the
central panel (see also point 2.1, subsection 3).
Each Crescendo step is programmable. To do this, use the [CRESCENDO] pedal to select the step
you require, switch on the voices and couplers of your choice, press [S], keep it pressed and then
press the general memories [HR] button.
3. [MAN. I] Swell Pedal: swell pedal used to regulate the volume of the first manual.
4. [MAN. III] Swell Pedal: this swell pedal is used to regulate the volume of the third manual.
5. General combination pistons (Vivace 90 Deluxe only): pistons used to recall the organ's general
combinations.
6. [TUTTI] foot piston: piston used to activate the Tutti. For a more detailed description, refer to point
13 of section 2.2.
Downloaded from www.Manualslib.com
CRESCENDO
I / P
III / II
I / II
II / I
1
manuals search engine
MAN. I MAN. III
2 3 4
50
Owner's Manual
6
TUTTI
5
4
3
2
1
5
6
