Set up the model before driving.
To change the transmitter settings, always stop the engine first or disconnect the motor wire.
When each lever is operated, a beeping sound will be heard.
Pay attention to servo linkages on R/C cars. If the servo function is forced to stop this may cause
excess current to build which will shorten servo life. Adjust with steering rate and steering ATV.
RIGHT AND LEFT TURN ADJUSTMENT FUNCTION ( STEERING ATV)
Hold the wheel to full lock right and operate the trim lever. Repeat this for full left lock.
This function ensures that the steering linkage does not lock.
STEERING RATE LEVER FUNCTION
Push the set up button and operate the steering trim lever to adjust the maximum
rudder angle of the steering servo. This is to ensure optimum running of your model.
STEERING TRIM LEVER FUNCTION
Keep the steering wheel in the neutral position and adjust the trim lever in order to set
up desired neutral position on the servo. 4 continuous quick beeps indicate the maximum
incremental positions. 2 continuous quick beeps indicate default neutral position.
This function ensures that the steering linkage does not lock.
THROTTLE TRIM LEVER FUNCTION
When operating this lever without holding the trigger, you can adjust the neutral position or stop
position. 4 continuous quick beeps indicate the maximum incremental positions.
2 continuous quick beeps indicate the default neutral position.
** Each trim position is indicated with a beeping sound
Left or backward
pipipipi
FORWARD AND REVERSE ANGLE ADJUSTMENT FUNCTION(Throttle ATV)
Hold the trigger to the forward position or reverse at maximum and then operate the throttle
trim lever can adjust the limits of the servo movement in each direction.
CHANGE SERVO ROTATION DIRECTION (Servo reverse)
You can adjust the steering reverse switch and the throttle reverse switch to
change the servo rotation direction.
RESTORE DEFAULT FUNCTION SETTING
Push the set up button for more than 2 seconds whilst keeping the wheel full lock
right, and the trigger full lock to forward, then release.
BATTERY ALARM
When the battery voltage is less than 6V, the LED will turn off, when the battery voltage is
less than 9V, the LED will flash and buzzer beep for 5S during operation. When this happens,
please change the batteries to new ones.
Neutral
pipi
8
Right or Forward
pipipipi
