4. Standard installation

5
6
1
Ref. Code
1 GOL4
2 LAMPH
XEL5
3
GOL4M
4 LAB9
FACIL3H
5
FACIL3EH
XEL2
6
LAB4
A
6
4
Transmitter
Flashing light
Key selector
Codified via radio control keyboard
Magnetic loop detection device for traffic monitoring
Gearmotor
Gearmotor and control panel incorporated
Photocells
Photocells IP55
Connector block (not supplied).
Connect the power supply to an approved omnipolar switch with an opening distance of
the contacts of at least 3mm (not supplied).
The connection to the mains must be made via an independent channel, separated from
the connections to command and safety devices.
5
6
