DE Gebrauchsanleitung / Montageanleitung EN Instructions for use / assembly instructions KO 사용 설명 / 설치 설명서 PuraVida 15070008 / 15070408 PuraVida 15072008 / 15072408 PuraVida 15075008 / 15075408...
(siehe Seite 9) Montagehinweise mit EcoSmart® • Die Armatur muss nach den gültigen Normen montiert, ohne EcoSmart® gespült und geprüft werden. • Im Fall, dass Wasser an der Armatur Richtung Schaft Serviceteile6(siehe Seite 5) fließt, muss der Strahlformer durch einen Standard Luftsprudler 13913000 ersetzt werden. Bedienung6(siehe Seite 10) • Bei Problemen mit dem Durchlauferhitzer oder wenn mehr Wasserdurchsatz gewünscht wird, kann der EcoSmart® (Durchflussbegrenzer), der hinter dem Reinigung6(siehe Seite12) und Luftsprudler sitzt, entfernt werden. beiliegende Broschüre • Hansgrohe Armaturen können in Verbindung mit hydraulisch und thermisch gesteuerten Durchlauf- erhitzern eingesetzt werden, wenn der Fließdruck Sonderzubehör mindestens 0,15 MPa beträgt. Installationskittnicht im Lieferumfang • Das Ablaufventil darf nur in Waschbecken mit Über- enthalten lauf eingesetzt werden. Technische6Daten Armatur6serienmäßig6mit6EcoSmart®6 (Durchflussbegrenzer) Betriebsdruck: max. 1 MPa Empfohlener Betriebsdruck: 0,1 – 0,5 MPa Prüfdruck: 1,6 MPa (1 MPa = 10 bar = 147 PSI) Heißwassertemperatur: max. 80°C...
Seite 3
6 The hot and cold supplies must be of equal pressu- res. Installation6Instructions Flow6diagram6 (see page 9) • The fitting must be installed, flushed and tested after the valid norms. with EcoSmart® without EcoSmart® • If the water is flowing along the fixture in the direction of the shaft, the spray former must be replaced with a standard air bubbler 13913000. Spare6parts6(see page 5) • If the instantaneous water heater causes problems or if you wish to increase the water flow, the EcoSmart® Operation6(see page 10) (flow limiter) located behind the aerator can be removed. • Hansgrohe mixers can be used together with hydrau- Cleaning6recommendation6(see lically and thermically controlled continuous flow page12) an enclosed brochure heaters if the flow pressure is at least 0,15 MPa. • The drain valve may only be installed in basins with an overflow opening. Special6accessories Technical6Data Installation kitorder as an extra This6mixer6series-produced6with6EcoSmart®6 (flow limiter) Operating pressure: max. 1 MPa Recommended operating pressure: 0,1 – 0,5 MPa Test pressure: 1,6 MPa (1 MPa = 10 bar = 147 PSI) Hot water temperature: max. 80°C...
Seite 4
EcoSmart® 포함 사 채널은 기본 에어레어터 13913000로 교체해 EcoSmart® 비포함 야 합니다. 서비스 부품(5 페이지 참조) • 순간온수기에 문제가 있거나 더 많은 유량을 원 할 때에는 에어레이터 후방에 있는 EcoSmart®(유 량 제한기)를 떼어냅니다. 작동6(페이지 10 참조) • Hansgrohe 수전은 유압이 최소 0.15MPa일 때, 유 압 및 열 제어 순간온수기와 함께 사용할 수 있 습니다. 세척 (페이지12 참조) 첨부된 브 • 폽업 밸브는 오버플로 밸브와 함께 세면대에만 로셔 설치합니다. 기술 제원 특수 부속품 시리즈별로 EcoSmart®(유량 제한기)가 있는 수 전. 설치 키트제품 구성에 포함되어 있지...
