Technical description and basic information

Model­ Power
MI30 300 W
MI50 500 W
MI100 1000 W
MI150 1500 W
MI200 2000 W
MI250 2500 W
MI300 3000 W
TMI100 1000 W
TMI150 1500 W
TMI200 2000 W
TMI250 2500 W
TMI300 3000 W

Safety features

☝
Please note!
Restart necessary!
The inverter is equipped with several safety features to protect the inverter and all its
components as for example the batteries .
The inverter is equipped with a thermic and electronic over-/undervoltage protection . If
the value is far below or far above the required limit, the device shuts itself down auto-
matically and has to be switched on again using the on/off button before its restart .
In the following situations the inverter shuts itself down automatically:
• internal temperature too high
• required output load too high
• input voltage too high or too low
42
[
ECTIVE
® POWER INVERTER – MI-/TMI-SERIES
Dimensions (LxWxH)
165 × 105 × 55 mm
190 × 105 × 55 mm
210 × 150 × 70 mm
250 × 220 × 90 mm
290 × 220 × 90 mm
320 × 220 × 90 mm
320 × 220 × 150 mm
300 × 150 × 75 mm
380 × 220 × 95 mm
410 × 220 × 95 mm
440 × 220 × 95 mm
480 × 220 × 150 mm
Empty weight
0,9 kg
1,2 kg
2,5 kg
4,7 kg
5,5 kg
6,2 kg
6,4 kg
2,6 kg
4,9 kg
5,7 kg
6,5 kg
6,7 kg
]
