INTERFACE
Installation
Installing the warning device on the DIN rail
Snap the device onto the DIN rail as follows:
EN
3.3

Connection

Before mounting the device, read the chapter on "Safety," in particular the section on
"Installation and commissioning". Do not remove the identification plate.
Warning!
Risk of short circuit
Injuries and damage to the device are possible when working with live parts.
•
•
Connect the devices as shown in the following illustration.
8 - EN
Before working on the device, always disconnect the supply voltage.
Connect the device to the supply voltage only after completion of the work.
Click!
