Using the brush attachments
Turbo brush for floors/carpets (1)(draw-
ings 11-12)
The turbo brush can be used to vacuum
floors, rugs and carpets with long or short
pile, and is ideal for picking up animal fur.
The cylindrical brush with hard bristles ro-
tates under the action of the air current and
its bristles effectively remove animal fur
and loose carpet and rug fibers.
Note: Never use the turbo brush to
clean rugs with fringe and pile of 15 mm
or more, because the rotating brush
can cause damage to such rugs. Do not
run the turbo brush over power cords
and turn off the vacuum cleaner imme-
diately after you are done using it.
Universal brush attachment (17)
1. For cleaning furniture upholstery.
2. With attached brush: for cleaning fur-
niture, curtains, books, floor-lamps,
shelves, and to remove dust from
plants.
Attachment for hard-to-reach places
(18)
For cleaning radiators, crevices, corners
and between sofa pillows.
Note: Attachments (17) and (18) are lo-
cated on the rear of the vacuum clean-
er.
USAGE INSTRUCTIONS
Before using the vacuum, pull the power
cord out to the desired length and insert
the plug into an outlet. The yellow mark
on the power cord warns you when to
stop pulling. Never pull the power cord
past the red mark.
Always make sure the dust container and
filter unit are attached before turning on the
vacuum cleaner.
1. To turn the vacuum cleaner, press the
1825.indd 7 1825.indd 7
ON/OFF button (5).
2. To rewind the power cord, press the
power cord rewind button (9) and guide
the rewinding process with your hand to
prevent entanglement.
3. While using the vacuum, you can regu-
late the suction power by moving the
regulating handle (8) and mechanical
regulator located on the handle of the
flexible hose.
SERVICING
1. Removing the dust container (4) and
emptying dust and trash from it (draw-
ing 6).
• Turn off the vacuum cleaner and unplug it
from the power outlet.
• Turn the self-cleaning handle of the
HEPA-filter (13) clockwise/counterclock-
wise.
• Lift the handle on the dust container and
pull it off.
• Press the fixation button of the lower lid
(16) to remove trash and then close it.
• Set the dust container (4) in place and
lightly press on it from above on to snap it
into place.
Note: We recommend emptying the
dust container after every use of the
vacuum cleaner.
2. Dissembling the dust container
(drawing 5).
• Turn off the vacuum cleaner and unplug
it from the power outlet. Disconnect the
dust container, empty dust and trash
from it and close the lower lid.
• Turn the top lid of the dust container
counterclockwise and remove the lower
part of the dust container.
• Holding the lower part of the filter unit,
turn it counterclockwise and disconnect
it from the top lid.
3. Cleaning the filter unit (drawing 7)
Always make sure the filter unit is clean,
7
