The manufacturer will not be held respon-
sible for damage or injuries caused by use
outside that stipulated by the manual or by
improper handling.

General description

The illustration of the princi-
pal functioning parts can be
found on the foldout page.

Extent of the delivery

Carefully unpack the appliance and check
that it is complete.
Dispose of the packaging material cor-
rectly.
- Device with safety key
- Grass shear blade with blade guard
- Shrub shear blade with blade guard
- Recharger
- Instruction Manual

Function description

The cordless grass & shrub trimmer is a
combination unit with two interchangeable
cutting devices. These are coated with plas-
tic (Telon non-stick coating) to prevent rust.
For use as a shrub trimmer, a double-sided
blade block is used as the cutting head.
The catching blades are round off at the
side to prevent accidents, and positioned
in an offset arrangement to reduce the
risk of injury. A cutting head with several
blades is provided for use as a grass trim-
mer. The safety key protects the devices
from being started unintentionally.
Please read the following descriptions for
the function of the various controlling parts
of the unit.
22

Overview

Equipment
1 Cutter head
2 Charge display (LED)
3 Switch lock, unit
4 Unlocking mechanism for turning
the cutter head
5 Unit handle
6 Charging socket
7 Safety key
8 On/off switch, unit
9 Unlock buttons
Cutter
10 Grass cutter blade
11 Blade guard
for grass cutter blade
12 Shrub shear blade
13 Blade guard
for shrub shear blade
Battery charger
14 Power supply unit
15 Recharger cable plug
16 Plug-in connector

Technical data

Unit
Motor voltage U ............................ 4 V
Rated speed .......................... 1100 min
Protection class ................................... III
Protection category...........................IPX1
Grass-trimming blade
Cutting width ............................73 mm
Blade width ..............................80 mm
Shrub-trimming blade
Cutting length ........................120 mm
Distance between teeth ....approx. 8 mm
Weight (incl. accessories) .. approx 0.89 kg
Sound pressure level
) ...................63.0 dB(A), K
(L
pA
-1
= 3 dB
pA
