Milnor MWF27J8 Handbuch Seite 27

Table 6: Bearings and Bushings. See
Mark
Do this each
1 2 3 4 5 6
Grease plate 01 10025W for bearing housing. See
x 200 hours
Table 7: Motor Grease Schedule. Use the data in
Motor Identification
(example: main drive)
Table 8: Mechanisms and Settings
Make sure mechanisms are serviceable and settings are correct to prevent unsatisfactory
Mark
Do this each
1 2 3 4 5 6
x 2400 hours
x 200 hours
x 200 hours
Table 7 for Motors.
Apply grease to these components to prevent damage.
Component
bearing seal
Section 3.1.4.3
Interval Quantity
Years Hours fl oz mL
performance.
Component
controller circuitry
water pressure regulator for
optional supply injector
bath level sensor that uses air
pressure
23
Chapter 3. Routine Maintenance
More Data. See also
"Lubricant Identification and Procedures"
Figure 13 and Section 3.1.4.2.
See Figure 14. Add 0.12 oz. (3.54 mL) of
grease EPLF2 (Table
to complete this table.
Dates When Grease is Added
Examine wiring and connections in electrical
boxes. Look for corrosion, loose connections.
See Section 3.1.3
See Figure 10. Value: 28 PSI (193 kPa).
Examine the air tube and connections. See
Figure 11
PELLERIN MILNOR CORPORATION
Section 3.1.4
10)
.
More Data
