The Si-82 centrifugal monobloc pumps are designed for use with all kinds of Air conditioning units, refri-
geration display cabinets, fan coil units and gas condensing boilers. They can also be used with gas fired
furnaces. The pump can be used to remove acid condensates (pH > 2.5) and condensates with a tempe-
rature of up to 65°C.
Technical specification :
Mains supply
Safety switch
EN
Max. flow rate
Max. discharge head
Operating time
Noise level in application
Water levels (mm)
Max. condensate tempera-
ture & acidity
Tank volume
Thermal protection
(overheat)
Protection
Actual flow rates (l/h)
The head losses defined in this table are calculated with
a Ø 10 mm int. hose.
Vertical Total tubing length
discharge
5 m
head
1 m 380
2 m 310
3 m 240
4 m 150
5 m 30
WARNING
- This pump has been designed for use with water only.
- This pump has been designed for indoor use only. It must not be immersed and/or placed in areas of high
humidity or where the ambient temperature conditions are below freezing.
- The appliance is not to be used by children or persons with reduced physical, sensory or mental capabili-
ties, or lack of experience and knowledge, unless they have been given supervision or instruction.
- Children should be properly supervised to ensure they do not play with the appliance.
- In case of breakdown, in particular if the supply cord is damaged, it must be replaced by a qualified person
in order to avoid any hazard.
WARNING:
attachment plug. To reduce the risk of electric shock, ensure that the pump is connected only to a suitable
grounding device.
1/ START UP
a/ Mains connection (Fig.10)
Connect the cable to the mains network in accordance with local wiring rules.
10
230V~ 50Hz - 70 W - 0.67 A
NC 4 A resistive - 250V
500 l/h
5.0 m
S3: 30% (3 s ON – 7s OFF)
45 dBA at 1 m (3.3 ft)
Fig. 4
t<65°C (80°C - 1min),
pH>2.5
2.0 l
105°C (auto-reset)
IP 20
10 m 20 m
300 240
260 200
200 145
130 80
20 0
Risk of electric shock. This pump is supplied with a grounding cable and a grounding
30 m
190
150
110
60
0
