Connecting/Disconnecting

CAUTION
Do not connect or disconnect the port replicator while the computer is powered on
or in the standby or hibernation mode.
Connecting
1
Power off the computer, and disconnect all cables from
the computer.
2
Connect the plug of the AC adaptor that came with the
E
computer to the DC-IN jack of the port replicator and
plug the other end into an AC outlet.
CAUTION
Do not use other than the specified AC adaptor (Model No. CF-AA1653A) and
AC cord.
Refer to the "Operating Instructions" accompanying computer for information
on proper handling of the AC adaptor and AC cord.
3
Open the front of the port replicator.
4
Align the right rear corner of the computer with the right
corner of the port replicator, then slowly lower the com-
puter.
CAUTION
Do not connect the computer to a port replicator
while the computer is connected to the AC adap-
tor or other cables.
Do not attempt to make connections if there is
any object between the computer and the port
replicator. Doing so could damage the computer
and the port replicator.
