Mounting of the encoder
• Fixation either by screws and shaft clamping.
Ensure that the encoder is mounted without
strain.
• Do not exceed the values for the maximum axial
and radial shaft load.
• Ensure accurate shaft alignment. If shaft and
flange are not correctly aligned, strain on the
bearings will result, which will overheat and be
irreparably damaged.

4. Electrical connection

• Switch power off before any plug is inserted or
removed!
• Any wiring must only be carried out without
power.
• Provide stranded wires with ferrules.
• Check all lines and connections before switching
on the equipment.
• The encoder's and follower electronic's (eg.
control unit) operating supply must be switched
on simultaneously.
• Encoders with parallel output: Unconnected
signal lines must be provided with a resistor (eg.:
R = 10 kOhm) and connected to earth.
Interference and distortion
All connections are protected against the effects
of interference. The location should be selected
to ensure that no capacitive or inductive in-
terferences can affect the encoder or the con-
nection lines! Suitable wiring layout and choice
of cable can minimise the effects of interference
(eg. interference caused by SMPS, motors, cyclic
controls and contactors).
Necessary measures:
• Only screened cable should be used. Wire cross sec-
tion is to be at least 0,14mm², max. 0,5mm².
• Wiring to the screen and ground (0V) must be
secured to a good point.
• The system should be positioned well away from
cables with interference; if necessary a protective
screen or metal housing must be provided. The
running of wiring parallel to the mains supply
should be avoided.
• Contactor coils must be linked with spark sup-
pression.
• With output circuit LD5 cable length is 3 meters
max. In case of a cable prolongation (> 3m),
signals must be refreshed by a repeater and it
6 IV28M/1
Power supply
Supply voltage depends on the unit type and is
indicated in the delivery documentation and on
the identification plate.
4.1 Connection type E1 (flying leads)
Output circuit PP
Output circuit OP/LD5/LD24
4.2 Connection type E6X
Output circuit PP (7pole plug)
Datum 23.07.2008
must be ensured that the encoder is connected
to 5V±5% supply voltage (for avoiding voltage
drop on cable).
PP/OP/LD24: +10 ... +30 V d.c.
LD5: +5 V d.c. ±5%
Colour
white
brown
green
yellow
grey
black
Colour
blue
green
red
yellow
pink
white
grey
brown
black
Pin Designation
1 channel B
2 +UB
3 channel 0/I
4 channel A
5 GND
6 ---
7 ---
Art.Nr. 84362
Designation
channel B
+UB
channel 0/I
channel A
GND
screening
Designation
channel /B
channel 0
channel I
channel A
channel /A
channel B
GND
+UB
screening
viewing side =
plug-in side
Änd. Stand 40/08
