3) Manual manoeuvre (only on versions with brake)
!
Release only when the rolling gate is stopped.
To release the gearmotor proceed as follows:
1
Turn the bottom of the knob clockwise to loosen it until you feel
a certain resistance;

4) Testing

Testing is the most important aspect of the installation procedure.
Each single component, such as the gearmotor, emergency stop,
photocells, etc., may require a specific testing procedure.
We recommend that you follow the directions provided in the relevant
instructions manuals.
Testing of the entire automation system must be conducted by expe-
rienced and qualified personnel, who must establish what tests are
necessary depending on the risks involved.
To test RONDO proceed as follows:
• Make sure that the fusible elements are in good condition, i.e. that
there are no breakages;

5) Maintenance

RONDO does not require any special maintenance. Scheduled
checks every six months will ensure the long life of the gearmotor and
the safe operation of the system.

5.1) Disposal

The automation system can be dismantled and scrapped without
any risks, since there are no dangerous components. Perform the
operations described in the "Mounting" chapter in the reverse order

6) Technical characteristics

RN2010 - RN2020 - RN2020/V1H6
RN2030 - RN2040 - RN2040/V1H6
Power supply / frequency
Absorbed current
Absorbed power
Max torque
Max lifting force with 200mm diameter
Nominal speed
Nominal torque
Rolling gate shaft standard diameter
Roller shutter flanges diameter
Crown rotation speed (loadless)
Operating ambient temperature
Class protection
Thermal protection
Continuous operating time
Max work cycle
Weight
Insulation class
*
48 and 42mm with supplied adapter
**
220mm with supplied adapter
2
Open or close the rolling gate manually;
3
Lock the gearmotor again by performing the contrary operation to
the one described at point 1.
• Make sure that the gearmotor is securely fastened to the spring shaft;
• Make sure that the screw connections have been well tightened;
• Make sure that the electrical contacts are in good condition;
• Make sure that the axial slack of the ring nut is not excessive;
• Check the adjustment of the limit switches by carrying out a com-
plete manoeuvre (up-down);
• Make sure that when the gearmotor is locked at any point, it dis-
plays no tendency to move;
• Make sure that the release device easily disengages the rolling
gate's gearmotor (only on versions with brake)
Maintenance simply consists in repeating the testing pro-
cedure.
RONDO is made out of various types of materials which must be dis-
posed of in compliance with the regulations in force.
The materials must be separated according to their type (electrical,
aluminium, plastic parts, etc.).
Reversible brakeless gearmotor
Non-reversible gearmotor with brake and release device
RN2010
RN2030
Vac/Hz
A
W
Nm
kg
Rpm
Nm
mm
mm
Rpm
°C
IP
°C
Minutes
sec
kg
RN2020
RN2040
230/50
2
2.6
450
600
130
130
8.5
75
60*
200*
10
-20 ÷ +50
20
140
4
50% with 30s ON and 30s OFF
9.5
F
GB
RN2020/V1H6
RN2040/V1H6
120/60
4.8
580
180
180
10
100
12
10
3
