Switching the measurement template on/off
Use this button to switch a measurement template on. This measurement graphic is
also saved in the images. If the function is deactivated, you will see the
To customise the template, go to the second page of device settings and then select
the button or press the display for 3 seconds when in live image mode to access
the menu.
Tap the icon or the
Tap the icon to call up the second page of device settings:
Selecting units
Tap this button in order to switch the measuring units on the measuring scale be-
tween millimetres (
Configuring the exposure correction
Tap this button to configure a set value for the exposure correction.
Values of , ,
of , , ,
shown in the centre of the display each time to select the next-lowest value each time.
After value , the screen changes to value
without correction.
Adapting measurement template
Tap this button to adapt a measurement template. Tap the bottom button to switch
between a rectangle and a circle as a template.
Tap the display in the current view in order to adjust the width of the rectangle using
the / buttons, the height of the rectangle using the
eter of the circle with the
