4. GENERAL SPECIFICATIONS

4.1 Dimensions and weight

70 x 193 x 37 mm

4.2 Clamp Tightening Capacity

≤ 26 mm

4.3 Power supply

A standard 9 V alkaline battery (type CEI 6LF22, 6LR61
or NEDA 1604). To change it, see §7.1.
Average battery charge life: 75 h or 25,000 x 10 s.
measurement
Battery charge indicator
Flashing: charge life < 1 h
Fixed: Change battery
Automatic OFF after 10 minutes with no action on the switch
or the keys (reactivation by switching from the OFF position
of the switch or by actuating any key)

4.4 Environmental parameters

Temperature - Humidity
90
80
70
60
50
40
30
20
10
0
-50 -40 -30
Altitude
- Operation: ≤ 2000 m
- Storage ≤ 12000 m
Indoor use
Impermeability: protection index IP 40 (according to EN
60529, ed. 92)

4.5 Compliance with norms

Electrical safety
(as per EN 61010-1 ed. 95 and 61010-2-032, ed. 93)
- Dual insulation:
- Installation category: III
- Pollution level: 2
- Rated voltage: 600 V (RMS or DC)
or - Installation category : IV
- Rated voltage : 300V (RMS or DC)
260 g
-20 -10 0 10
Temperature in °C
Reference range
Storage range (without battery)
42
+ :
-
20 30 40 50 60
Operating range
70 80 90
