It is imperative that the following sequence for the individual parameters is observed!
1. PIN
2. Priority
3. Key click
4. Pulse generator activation
5. Pulse generator delay (when pulse generator active)
6. Pulse generator CW key (when pulse generator active)
7. Pulse generator CCW key (when pulse generator active)
8. Pulse generator frequency (when pulse generator active)
If the pulse generator function is not activated, then the pulse generator parameters
"Pulse generator delay",
"Pulse generator CW key",
"Pulse generator CCW key"
"Pulse generator frequency"
do not need to be transferred.
Parameter
Explanation
no.
1 PIN: 1000s digit
2 PIN: 100s digit
3 PIN: 10s digit
4 PIN: 1s digit
5 Priority:
6 Key click
7 Pulse generator activation
8 Pulse generator delay 1000s
9 Pulse generator delay 100s
10 Pulse generator delay 10s
11 Pulse generator delay 1s
12 Pulse generator CW key
13 Pulse generator CCW key
14 Pulse generator freq. in Hz 100s
15 Pulse generator freq. in Hz 10s
16 Pulse generator freq. in Hz 1s
Error byte:
31H: Parameters transferred correctly
34H: Parameter transfer erroneous
095640-02-02/06
Hand-Held Pendant Station
Parameter value
Only figures 0-9 in HEX format 30H ... 39H
Only figures 0-9 in HEX format 30H ... 39H
Only figures 0-9 in HEX format 30H ... 39H
Only figures 0-9 in HEX format 30H ... 39H
30H = Control system has priority
31H = HBAS has priority
30H = Key click off
31H = Key click on
30H = Pulse generator inactive
31H= Pulse generator active
Only figures 0-9 in HEX format 30H ... 39H
Only figures 0-9 in HEX format 30H ... 39H
Only figures 0-9 in HEX format 30H ... 39H
Only figures 0-9 in HEX format 30H ... 39H
All keys except S2 (32H), S7 (37H),
S16 (40H), and S20 (44H)
All keys except S2 (32H), S7 (37H),
S16 (40H), and S20 (44H)
Only figures 0-9 in HEX format 30H ... 39H
Only figures 0-9 in HEX format 30H ... 39H
Only figures 0-9 in HEX format 30H ... 39H
