Menu structure: There are three menu levels. The levels below the indication of
the basic settings are always accessed from level 1 by pressing the control but-
ton for different lengths of time.
• Level 1 - Status indication (indication of the operating status)
• Level 2 - Operation menu (setting the basic functions):
• Press the control button for longer than 1 second
• Level 3 - Options menu (further settings):
• Press the control button for longer than 6 seconds
NOTE: After 30 s without any entry being made, the display jumps back to level
1 (indication of the operating status). Temporary, non-acknowledged modifi-
cations are discarded.

7 Installation and electrical connection

DANGER! Risk of fatal injury!
Incorrect installation and inexpert electrical connection can pose a risk of
fatal injury. Danger from electrical current must be ruled out.
• Installation and electrical connection may only be carried out by qualified
personnel and in accordance with the applicable regulations!
• Accident prevention regulations must be observed!
• Comply with the regulations of the local power supply company!
Pumps with pre-assembled cable:
• Never pull on the pump cable!
• Do not kink the cable!
• Do not place any objects on the cable!

7.1 Installation

WARNING! Risk of injury!
Incorrect installation can result in injuries.
• There is a crushing hazard!
• There is a risk of injury due to sharp edges/burrs. Wear appropriate protec-
tive clothing (e.g. safety gloves)!
• There is a risk of injury hazard due to the pump/motor falling! Use suitable
lifting gear to secure the pump/motor against falling!
CAUTION! Risk of damage to property!
Incorrect installation can result in damage to property.
• Have installation work performed by qualified personnel only!
• Observe national and regional regulations!
• When the pump needs to be transported, it may be carried only by the motor/
pump housing. Never at the module/terminal box or pre-assembled cable.
• Installation within a building:
Install the pump in a dry, well-ventilated room. Ambient temperatures below
-10°C are not permissible.
