2.13 Fixing of the appliance

a. Fix the appliance on the built-in
unit by turning the screws.
b. Press the 4 plugs into the holes
(look at figure).
c. Use woodscrews ST* 4*26 (self-
tapping screws) for the left and
right as well as for the 4 top holes.
1: plug

2.14 Fixing of the top spacer

(Equipment depending on model)
The top spacer has got several layers.
Customize the height of the spacer by
removing the relevant number of layers
from the bottom side of the spacer. Use
the click-mechanism for selecting the proper
number of layers.
1: spacer
57
