ENGLISH
SL-32 DSB: Rear Panel
ON/OFF
1 DC Terminal
2 Ein- / Ausschalter
3 Headphone Output Terminal
4 Coaxial Output Terminal
SL-32 DSB: Side Panel
RF IN RF IN
DVB-S/S2 DVB-T/T2/C
1 DVB-S / S2 Input Terminal
2 DVB T / T2 / C Input Terminal
3 YPbPr Input Terminal
4 AV Input Terminal
HDMI 1 HDMI 2 PC IN
PC AUDIO USB
V L R
AV OUT
5 HDMI Input Terminal
6 HDMI Input Terminal
7 PC IN Input Terminal
8 AV Output Terminal
5 PC IN: Audio
6 USB Input Terminal
