Parent Unit - Luvion Grand Elite Betriebsanleitung

Parent unit

Antenna Recieves the video and sound from the baby unit.
1.
Antenna locking switch Slide the switch to the unlock position, to make the
2.
antenna pop up and improve reception.
Record Press this button to start recording, press it again to stop recording.
3.
4. Menu button Press this button to enter the main menu.
Navigation buttons The navigation buttons can be used when the system is in
5.
normal use and/or when you are in the menu.
Normal use
• Press left (A) to automatically switch between multiple cameras. The screen
changes channel every 3 seconds
• Press right (M) to switch manually between multiple cameras
Use in the menu
Press the
6. SCAN When SCAN is pressed, the screen is turned off. During this time the parent
unit will continuously scan the baby unit (or multiple baby units). When a sound
is detected, the parent unit will become active. Now you can see what happens
in the baby room. You can adjust the sound sensitivity for this detection with the
rotary knob at the side of the camera. After the parent unit has detected sound it
will take about 5 seconds to switch back to the scan mode. Except when the sound
is continously detected. In that case the monitor will be activated for another 5
seconds. There are 2 reasons to use the scan button: 1- to prevent you from being
disturbed by the bright LCD screen, or 2- to save energy. Press the scan button again
to deactivate the scan mode.
Coloured LEDs The green LED indicates that the monitor is switched on. The green/
7.
red LEDs indicate the volume level of the camera (from low to high).
LCD screen Displays the video from the baby unit.
8.
9. Microphone Recieves sound from the area around the parent unit and transmits it to
the baby unit. This will only happen when the Talk back button is pressed.
10. Alarm button This button enables you to increase or decrease the volume of the
alarm. The alarm is activated when the monitor is switched on by for example the
cries of the baby, because it is possible that the cries will not wake you. Note this is
not the volume button!
Night light Press this button on the parent unit to remotely turn on/off the night
11.
light on the baby unit.
Charging indication LED The LED is red when the built-in batter is being charged
12.
and green when it is fully charged.
DC 5V power adapter Connect the included DC 5V power adapter to power and/or
13.
charge the parent unit.
Note: Use the right DC 5V socket for the power adapter. Do not use the AV- OUT socket.
AV/OUT Audio-video socket which allows you to connect a television or monitor to
14.
the parent unit, using the RCA cable. When the RCA cable is connected the screen will
turn black.
6
buttons to navigate in the menu. To confirm your selection press OK.
