Baumer PosCon OXE7 Bedienungsanleitung Seite 48

11111452
OXE7.E25T-11111452
Breite / Höhe / Länge 26 / 74 / 55 mm
Bauform quaderförmig, frontale Optik
Gehäusematerial Aluminium
Frontscheibe Glas
Anschlussart Stecker M12 8-polig
Gewicht 130 g
Umgebungsbedingungen
PosCon OXE7
11111452
OXE7.E25T-11111452
Fremdlichtsicherheit < 25 kLux
Arbeitstemperatur -20 ... +50 °C
Lagertemperatur -25...+75 °C
Schutzart IP 67
Vibrationsfestigkeit (sinusförmig) IEC 60068-2-6:2008
7.5mm p-p for f = 2 - 8Hz
2g for f = 8 – 200Hz, or 4g for
200 – 500Hz
Resonanztest IEC 60068-2-6:2008
1.5mm p-p for f = 10 - 57Hz ,
10 cycles for each axis 10g for
f = 58 -2,000Hz, 10 cycles for
each axis
Vibrationsfestigkeit (Zufall) IEC 60068-2-64:2008
Spectrum: 0.1 g2/Hz for 20 –
1,000Hz, 30 minutes / axis
(>10gRMS)
Schockfestigkeit IEC 60068-2-27:2009
50g / 11ms or 100g / 6ms, 10
shocks in each axis and each
direction
100g / 2ms, 5,000 shocks in
each axis and each direction
Stossfestigkeit IEC 60068-2-27
100g / 2ms, 4,000 shocks in
each axis and each direction
de_BA_PosCon_OXE7.docx
21.03.2018 15:20/tof V1.2 ANW_81125407
11174280 11148276
OXE7.E25T-11174280 OXE7.E25T-11148276
26 / 74 / 55 mm 26 / 74 / 55 mm
quaderförmig, frontale Optik quaderförmig, frontale Optik
Aluminium Aluminium
Glas Glas
Stecker M12 8-polig Stecker M12 8-polig
130 g 130 g
PosCon OXE7 PosCon OXE7
11174280 11148276
OXE7.E25T-11174280 OXE7.E25T-11148276
< 35 kLux < 35 kLux
-20 ... +50 °C -20 ... +50 °C
-25...+75 °C -25...+75 °C
IP 67 IP 67
IEC 60068-2-6:2008 IEC 60068-2-6:2008
7.5mm p-p for f = 2 - 8Hz 7.5mm p-p for f = 2 - 8Hz
2g for f = 8 – 200Hz, or 4g for 2g for f = 8 – 200Hz, or 4g for
200 – 500Hz 200 – 500Hz
IEC 60068-2-6:2008 IEC 60068-2-6:2008
1.5mm p-p for f = 10 - 57Hz , 1.5mm p-p for f = 10 - 57Hz ,
10 cycles for each axis 10g for 10 cycles for each axis 10g for
f = 58 -2,000Hz, 10 cycles for f = 58 -2,000Hz, 10 cycles for
each axis each axis
IEC 60068-2-64:2008 IEC 60068-2-64:2008
Spectrum: 0.1 g2/Hz for 20 – Spectrum: 0.1 g2/Hz for 20 –
1,000Hz, 30 minutes / axis 1,000Hz, 30 minutes / axis
(>10gRMS) (>10gRMS)
IEC 60068-2-27:2009 IEC 60068-2-27:2009
50g / 11ms or 100g / 6ms, 10 50g / 11ms or 100g / 6ms, 10
shocks in each axis and each shocks in each axis and each
direction direction
100g / 2ms, 5,000 shocks in 100g / 2ms, 5,000 shocks in
each axis and each direction each axis and each direction
IEC 60068-2-27 IEC 60068-2-27
100g / 2ms, 4,000 shocks in 100g / 2ms, 4,000 shocks in
each axis and each direction each axis and each direction
48/74
11177353
OXE7.E25T-11177353
26 / 74 / 55 mm
quaderförmig, frontale Optik
Aluminium
Glas
Stecker M12 8-polig
130 g
PosCon OXE7
11177353
OXE7.E25T-11177353
< 35 kLux
-20 ... +50 °C
-25...+75 °C
IP 67
IEC 60068-2-6:2008
7.5mm p-p for f = 2 - 8Hz
2g for f = 8 – 200Hz, or 4g for
200 – 500Hz
IEC 60068-2-6:2008
1.5mm p-p for f = 10 - 57Hz ,
10 cycles for each axis 10g for
f = 58 -2,000Hz, 10 cycles for
each axis
IEC 60068-2-64:2008
Spectrum: 0.1 g2/Hz for 20 –
1,000Hz, 30 minutes / axis
(>10gRMS)
IEC 60068-2-27:2009
50g / 11ms or 100g / 6ms, 10
shocks in each axis and each
direction
100g / 2ms, 5,000 shocks in
each axis and each direction
IEC 60068-2-27
100g / 2ms, 4,000 shocks in
each axis and each direction
Baumer Electric AG
Frauenfeld, Switzerland
