A Overview of the Appliance Components
Dust space lid
1
Suction opening
2
"Dust bag full" display
3
Power controller
4
Button to wind up the cable
5
ON/OFF switch
6
Unlocking device for the dust compartment
7
Exhaust filter
8
Motor protection filter: Plastic foam filter or micro
9
hygiene filter (depending on the configuration)
Holder for filter bridge
10
Carrying handle
11
Vacuum hose with air leak slider
12
Telescopic tube (depending on the configura-
13
tion)
14 Switchable floor nozzle (depending on the
configuration)
Assembly
B
Insert hose (B1)
Push the vacuum hose into the suction opening on the top of the vacuum cleaner so that it audibly
snaps into place.
If you would like to remove the hose, then press the two opposing buttons and pull it out.
Insert vacuum tube (B2)
Push the narrow end of the vacuum tube into the floor nozzle and rotate the tube back and forth at the
same time to get a better hold.
Push the handle of the vacuum hose onto the vacuum tube and close the air-leak slider if necessary. (B3)
Ratchet telescopic tube (B4) (varies depending on the appliance model)
This adjustable vacuum tube can be lengthened to fit your height to make your work more convenient.
Loosen the locking device by pressing the button in the direction of the arrow. Set the vacuum tube
to the desired length. To lock the vacuum tube in the desired length, release the button and push the
suction tube in a little until you hear the lock click.
Rotary telescopic tube (B5) (varies depending on the appliance model)
This adjustable vacuum tube can be lengthened to fit your height to make your work more convenient.
Hold the narrower end of the tube firmly with one hand. With your other hand, unlock the tube by
turning the lock to the left. Set it to the desired length and then relock the tube by turning to the right.
Pay attention to the instructions stamped on the tube.
Vacuum cleaner bag with cardboard seal
15A
Vacuum cleaner bag with plastic seal
15B
Filter bridge
16
Furniture Brush (depending on the configuration)
17
Upholstery nozzle (depending on the configuration)
18
Joint and crack nozzle
19
Holder for vacuuming fittings in the storage position
20
Turbo nozzle (depending on the configuration)
21
Hard floor nozzle (depending on the configuration)
22
Permanent filter box container (depending of the
23
configuration)
Filter screen (depending on the configuration)
24
Plaited filter (depending on the configuration)
25
Permanent filter box lid (depending of the configu
26
ration)
Brush (depending on the configuration)
27
Floor nozzle (depending on the configuration)
28
29 Floor nozzle (depending on the configuration)
