8

TECHNICAL INFORMATION

Accessories
Battery Type
Electrodes
Lead Wires
Standard Measurement Conditions
Output Specifications
Waveform
Current Range (100Ω to 12kΩ load)
Root Mean Square/ Effective Value
(1kΩload)
Dose Range (1mA/min increments)
Dose Accuracy
Ramp Up/ Ramp Down

Battery Information

Supply Voltage Range
Low Voltage Indicator Threshold
Low Voltage Shutdown
Expected Battery Life (one channel @
4mA)
IEC 601 Standard Classification

Physical Dimensions

Size (H x W x D)
Approx. Weight (without battery)

Environmental Conditions:

Transportation and Storage
Operation
9V Alkaline battery.
Any Chattanooga Iontophoresis electrode with a
minimum active area of 8cm 2 .
Any Chattanooga Iontophoresis lead wire with the
standard device connection as pictured.
77° F (25° C); 8.5V d.c. supply voltage
± 15% unless noted
Constant direct current
0.5 to 4mA ±10%
<10mA
0 to 160 mA/min
± 2 mA/min
30s
5.6V to 10V
6.5V
5.3V
7h (1700 mA/min)
Type BF Applied Part. Internally powered
only. Ordinary protection against entry of
liquids. Continuous operation. Not suitable
for use in the presence of a flammable
anaesthetic mixture with air or with oxygen
or nitrous oxide.
3.7in H x 2.4in W x 0.9in D
(9.4cm H x 6.2cm W x 2.2cm D)
2.45oz (77g)
-13° F to 176° F (-25° C to +80° C); 90% humidity
@ 104° F (40° C); normal atmospheric pressure.
Store in a cool, dry place.
50° F to 104° F (10° C to +40° C)
