1. EDIFIER ConneX app
With this app, you can
•control play from the Bluetooth
source device,
•control the master volume,
•upgrade the firmware, and
•more functions.
Download EDIFIER ConneX app
1. With your smart device, scan the QR code on the quick start guide or the
packaging.
•You can also search for "EDIFIER ConneX" in Apple App Store (iOS devices) or
Google Play (Android devices).
2. Download and install the app.
How to use this app
1. Connect your smart device with the speaker via Bluetooth.
2. In Bluetooth mode, open EDIFIER ConneX App on your smart device.
3. Tap the menu for settings and playback control.
2. What's in the box?
Strap
Note:
•Images are for illustrative purpose only and may differ from the actual product.
•For the need of technical improvement and system upgrade, information and
specifications contained herein may be slightly different from actual product.
If any difference is found, the actual product prevails.
3. Charging
5V
2A
Note:
•Power input: 5 V
•"5" is the minimum power required by the radio equipment to charge.
"10" is the maximum power required by the radio equipment to achieve
maximum charging speed.
4. Power on/off
Press and hold the "
5. Bluetooth connection
This speaker supports the simultaneous connection of two Bluetooth devices.
Connect to a device
1. If no device is connected, the speaker will auto-enter Bluetooth pairing mode after
powered on (LED blinking in blue). If not, press and hold the "+" and "-" buttons for
1.5 seconds.
2. On your device, select "EDIFIER ES20" in its Bluetooth device list to connect, and the
blue LED will be steady lit when the connection is established.
•To disconnect from the current Bluetooth device, press and hold the "+" and "-"
buttons for 1.5 seconds.
Connect to two devices
1. Connect to a device, and then press and hold the "+" and "-" buttons for 1.5 seconds
(LED blinking in blue).
2. On the second device, select "EDIFIER ES20" in its Bluetooth device list to connect,
and the blue LED will be steady lit when the connection is established.
3. On the first device, select "EDIFIER ES20" in its Bluetooth device list to reconnect.
•Pause or stop playback on the current Bluetooth device before streaming audio from
the second one.
Note:
•Pin code for connection is "0000" if needed.
•To enjoy all Bluetooth functions of this product, make sure that your audio source
device supports HFP, A2DP and AVRCP profiles.
•If no device is connected in 10 minutes, the speaker will switch to Bluetooth hidden
mode. The blue indicator will blink slowly. In this mode, (1) new devices cannot find
the speaker, but (2) for a device that exists in the pairing record of this speaker, you
can select "EDIFIER ES20" from its Bluetooth device list to reconnect. To exit from
Bluetooth hidden mode, press "
•After powered on, the speaker will reconnect to the last connected devices
automatically.
6. Bluetooth stereo pairing
Pair two ES20 speakers to enjoy stereo sound.
1. Double press the "
pattern.
2. Double press the "
breathing pattern.
• Once the connection is established, the white LED on the first ES20 will be steady
lit or blink rapidly, and the white LED on the second ES20 will light off.
3. Connect the first ES20 to your Bluetooth device and start playing.
• To exit the stereo mode, double press the "
Note:
• The first ES20 will work as the master speaker. You can control play on the first
ES20.
• The first ES20 will deliver the right channel audio and the second one is for the left
channel audio.
7. Play control
8. Phone calls
9. Light effects
ON
x1 :
10. Specifications
Total output power (RMS): 6 W
Frequency response: 93 Hz-19 kHz
Declaration for EU
Frequency Band: 2.402 GHz ~ 2.480 GHz
RF Power Output: ≤13 dBm (EIRP)
There is no restriction of use.
11. Troubleshooting
Cannot connect to your Bluetooth device
Make sure that the distance between this product and your Bluetooth device
is less than 10 meters and there are no obstacles between them.
Make sure that no device is connected to this product via Bluetooth.
Make sure that this product is in Bluetooth pairing mode. If not, manually
switch it to this mode.
Restart this product, enable Bluetooth function on your Bluetooth device,
and then try again.
No sound
Make sure that this product is powered on.
Make sure that this product and your device is properly connected.
Make sure that the playback is not paused.
Make sure that this product and your device are not muted.
Increase the volume of this product and your device.
Noise coming from speakers
EDIFIER speakers generate little noise, while the background noise of some
audio devices are too high. Please unplug audio cables and turn the volume
up. If no sound can be heard at 1 meter away from the speaker, there is no
problem with this product.
To learn more about EDIFIER, please visit www.edifier.com
For EDIFIER warranty queries, please visit the relevant country page on
www.edifier.com and review the section titled Warranty Terms.
USA and Canada: service@edifier.ca
South America: Please visit www.edifier.com (English) or
www.edifierla.com (Spanish/Portuguese) for local contact information.
ES20
Portable Bluetooth Speaker
Quick Start Guide
Model: EDF286009
USB-C to USB-C audio cable
2 A
" button for 1.5 seconds to power on/off the speaker.
" button on the speaker.
x2
Settings
Bluetooth
DEVICES
EDIFIER ES20
" button on the first ES20. The white LED will be in breathing
" button on the second ES20. The white LED will be in
x1
x1
1.5s
1.5s
Speaker
ON
2:12
Settings
Bluetooth
Bluetooth
DEVICES
EDIFIER ES20
1.5s
2:12
Bluetooth
" button.
x1
x1
OFF
x2 :
EDIFIER ConneX app
Quick start guide
1.5s
OFF
1.5s
x2
5-10
W
