276 Spezifikationen

Parameter Change- und Request-Format

Spezifikationen
STATUS
11110000 F0
ID No.
01000011 43
SUB STATUS
0001nnnn 1n
MODEL ID
00111101 3d
PARAM TYPE
0ttttttt tt
0ddddddd dd0
DATA
:
0ddddddd ddn
EOX
11110111 F7
STATUS
11110000 F0
ID No.
01000011 43
SUB STATUS
0011nnnn 3n
MODEL ID
00111101 3d
PARAM TYPE
0ttttttt tt
0ddddddd dd0
DATA
0ddddddd dd1
0ddddddd dd2
EOX
11110111 F7
type number:
0 edit buffer( used byte or bit operation format)
1 setup( used byte operation format, request and response for request only)
2 backup( used byte operation format, request and response for request only)
24 recall/store( parameter change only)
25 key remote( parameter change only)
r Remote( parameter change only)
26 fader/encode
02R Bedienungsanleitung
PARAMETER CHANGE (basic format)
System Exclusive Message
Manufacturer's ID No.(YAMAHA)
n=0-15(Tx/Rx Channel No.1-16)
MODEL ID (02R)
(type number, bit6:0=byte 1=bit operation)
data 0-n
:
End Of Exclusive
PARAMETER CHANGE REQUEST
System Exclusive Message
Manufacturer's ID No.(YAMAHA)
n=0-15(Tx/Rx Channel No.1-16)
MODEL ID (02R)
(type number, bit6:0=byte)
address( H) high 7 bits of 14 bits address
address( L) low 7 bits of 14 bits address
count
End Of Exclusive
