7. Maintenance work on wheel sets, exchanging
lower gear part and traction tires
(Fig. 4, Page 15)
Dismantle casing and circuit board, see item 2 to 3. Dismantle
gear part, see item 6. Remove power supply cable (8) from circuit
board. Unclip the bogie attachment (15) with a small screwdriver.
Remove endless screw (16) and cardan shaft (17) from holder.
The whole bogie (18) can now be removed downwards. Release
the bogie panel (28) carefully on one side, lift the gear cover (30)
with a small screwdriver and unclip. Now you can remove the
wheelsets (27). The traction tires can now be exchanged (28).
8. Refitting for HOe (Fig. 4, page 15)
For refitting follow the steps under point 7. Change the correspon­
ding parts (Pos. 53, page 18) which attached the package.
9. Exchanging the digital decoder (Fig. 4, Page 15)
Remove housing, see item 2.
Pull out digital decoder (33) and insert new one.
13
