6.7 Toggles & links (Toggles und Verlängerungen)
Toggle type
Eye/fork toggle
Fork/Fork toggle
W1
D1
D2
Eye/fork Extensionlink
D2
W1
Ø 4
Article no. 174-102
Length (H) 25
Ø Eye (D1) 8
Ø Clevis pin (D2) 8
Fork width (W2) 8
Article no. 517-056-02
Length (H) 25
Ø Clevis pin (D1) 8
Fork width (W1) 7.5
Ø Clevis pin (D2) 8
Fork width (W2) 8
Article no. 517-944-01
Length (H) 90
Ø Clevis pin (D1) 8
Fork width (W1) 7
Ø Hole (D2) 8.3
Gauge (W2) 4
Forestay Dimensions
Ø 5 Ø 6
174-103 174-104
35
10
9.5
10
517-054-02 517-046-02
30
10
10
10
11
517-945-01 517-063-01
90
10
9.5
10.3
4
40
11
11
12
40
12
11
10
11
90
12
11
13
6
37
