HEART RATE MEASUREMENT

Heart rate measurement using a heart rate belt:
For reliable heart rate monitoring during training, we recommend
wearing a suitable chest belt. The computer has a built-in receiver, so
you can use a heart rate belt, such as the Christopeit Sport heart rate
belt (item no.: 9309). If you moisten the heart rate belt a little before
you put it on, the computer should record and display the heart rate
data within 60 seconds. The range of the heart rate belts is 1 to 2 m
depending on the model.
Cleaning, Checks and Storage of the Ergometer
bike:
1. Cleaning
Use only a less wet cloth for cleaning. Caution: Never use benzene,
thinner or other aggressive cleaning agents for surface cleaning as
this damage caused.
The device is only for private home use and for use suitable indoors.
Keep the unit clean and moisture from the device.
2. Storage
Plug out the power supply unit while intending the unit for more
than 4 weeks not to use. Choose a dry storage in-house and put
some spray oil to the pedal bearings left and right. Cover the bike to
protect it from being discolor by any sunlight and dirty through dust.
3. Checks
We recommend every 50 hours to review the screw connections for
tightness, which were prepared in the assembly. Every 100 opera-
ting hours, you should put some spray oil at the pedal bearings left
and right.
Training area in mm
(for home trainer and user)
Hand pulse measurement:
The hand pulse sensors are located on the left and right
seat grips. Please make sure that both palms always rest on the
sensors at the same time with normal force. As soon as the pulse
decreases, a value is shown in the pulse display. (The hand pulse
measurement is only for orientation, since movement, friction,
sweat, skin texture and blood circulation, etc. can lead to individual
deviations from the actual pulse.)
Note: If both pulse measurement methods are used at the same
time, the hand pulse measurement has priority.
Attention! Heart rate monitoring systems may be inaccurate.
Excessive exercise can cause serious injury or death. If you feel
Free area in mm
(Training area and security area
(rotating 60cm))
Troubleshooting
If you cannot solve the problem with the following information, please
contact the authorized service center.
Problem Possible Cause
Computer has No power
no value at Dis- adapter is well
play if you press plugged or wall
any key. power is without
power.
Computer is Sensor impulse
not counting missing base on
data and do not not well plugged
switch on after connection
start cycling.
Computer is Sensor impulse
not counting missing base on
data and do not not correct positi-
switch on after on of sensor.
start cycling.
No pulse value Pulse cable is not
plugged in.
No pulse value Pulse sensors
not well connec-
ted
28
Solution
Check that the power adapter
is properly plugged in, possibly
with another electric device
check if the wall power is fine.
Check the plug connections at
computer and inside of handle-
bar support.
Take off the cover and check the
distance between magnet and
Sensor. The magnet at turning
belt wheel should have only less
than < 5mm distance against the
sensor position.
Check the separately pulse
cable is well connected with
computer.
Screw out the screw for pulse
measurement and check if
plugs are well connected and no
damage at pulse cable.
