GB
6.2 Fitting and adjusting the depth stop
(Fig. 4/Item 2)
Undo the thumb screw (a) on the additional
handle (8) and insert the depth stop (2) in the
hole of the additional handle.
Set the depth stop and retighten the thumb
screw.
Now drill the hole until the depth stop touches the
workpiece.
6.3 Fitting the drill bit (Fig. 10)
Always pull the power plug before making
adjustments to the equipment.
Release the depth stop as described in 6.2 and
push it towards the additional handle. This
provides free access to the chuck (1).
This hammer drill is fitted with a keyless chuck
(1).
Open the chuck (1). The drill bit opening must be
large enough to fit the drill bit into.
Select a suitable drill bit. Push the drill bit as far
as possible into the chuck opening.
Close the chuck (1). Check that the drill bit is
secure in the chuck (1).
Check at regular intervals that the drill bit or tool
is secure (pull the mains plug).
6.4 Fitting the dust extraction system (Fig. 5-9)
The dust extraction system (11) is fitted on the
additional handle (8). It can also be used in
combination with the depth stop (2). This prevents
the work area becoming very dirty.
Release the cover (A) and the sealing cap (B) by
turning the additional handle (8). Several drill bits
can be stored in the sealing cap (B) to save
space (Fig. 5-6).
Screw the dust extractor adapter (9) on to the
additional handle (8) from underneath.
Now place the dust extraction system (11) on to
the additional handle (8) as shown in Fig. 7 – 8
and secure it by turning it.
Important. There are detents on the cover (A)
and the dust extraction system (11) which
must be engaged in the corresponding
recesses on the additional handle (8) before
the cover (A) or dust extraction system (11)
can be turned and locked.
Remove the dust extraction system (11) by
following the above in reverse.
Fit the additional handle (8) on the machine as
described in 6.1. Please note that the additional
handle (8) must be fitted to the left-hand side of
the machine if the dust extraction system (11) is
also fitted (Fig. 9).
The dust extraction system (11) can be fitted to
the machine even if the additional handle (8) is
16
03.11.2010 10:14 Uhr Seite 16
fitted.
If the dust extraction system (11) is not required,
the cover (A) and the sealing cap (B) must be
fitted to the additional handle (8).
7. Operation
7.1 ON/OFF switch (Fig. 11/Item 5)
First fit a suitable drill bit into the tool (see 6.3).
Connect the mains plug to a suitable socket.
Position the drill in the position you wish to drill.
To switch on:
Press the ON/OFF switch (5)
Continuous operation:
Secure the ON/OFF switch (5) with the locking
button (4).
To switch off:
Press the ON/OFF switch (5) briefly.
7.2 Adjusting the speed (Fig. 11/Item 5)
You can infinitely vary the speed whilst using the
tool.
Select the speed by applying a greater or lesser
pressure to the ON/OFF switch (5).
Select the correct speed: The most suitable
speed depends on the workpiece, the type of use
and the drill bit used.
Low pressure on the ON/OFF switch (5): Lower
speed (suitable for: small screws and soft
materials)
Greater pressure on the ON/OFF switch (5):
Higher speed (suitable for large/long screws and
hard materials)
Tip: Start drilling holes at low speed. Then increase
the speed in stages.
Benefits:
The drill bit is easier to control when starting the
hole and will not slide away.
You avoid drilling messy holes (for example in
tiles).
7.3 Preselecting the speed (Fig. 11/Item 6)
The speed setting ring (6) enables you to define
the maximum speed. The ON/OFF switch (5) can
only be pressed to the defined maximum speed
setting.
Set the speed using the setting ring (6) on the
ON/OFF switch (5).
Do not attempt to make this setting whilst the drill
is in use.
