Divar 2 external CD/DVD writer | Installation Manual

Rear panel

On/Off
SCSI ID
Set the SCSI ID to a value between 0 and 6 (default 5). If you are using a disk array
make sure that the ID you select for the external CD/DVD writer is different from the
ID set on the disk array. (The default SCSI ID of the Divar itself is 7.)
Connection
Connect the external CD/DVD writer to the Divar first, then connect the disk array to
the external CD/DVD writer. If no disk array is used, be sure to connect the supplied
terminator to the second SCSI connector!
Plug and play
The external CD/DVD writer can be directly connected to the Divar without switching
it off. You only need to reboot if a SCSI cable is disconnected to place the external CD/
DVD writer between a storage array and the Divar. Select Detect writer (refer to the Disk
manager/Storage setup menu) to detect a connected CD/DVD writer for the first time.
This is only necessary if the Divar is switched on before the writer and if the writer's SCSI
ID is not 5 (the default). After switching on the external CD/DVD writer, wait
approximately 30 seconds before proceeding.
Bosch Security Systems
Downloaded from www.Manualslib.com
100-240 Vac Disk array or Terminator
manuals search engine
Divar
5
EN | 8
+
SCSI ID
–
