Dell HT118 Installationsanleitung Seite 25

Figure 1-10. Orientation for the Left or Right Cable-Management Arm Ramp Assembly
1
2 Fit the latch of the ramp assembly on the ramp assembly bracket, located
3 To slide the cable-management arm into place:
To disengage the cable-management arm ramp assembly, press the ramp
assembly release button on the ramp assembly latch and pull the ramp
assembly off the bracket (see Figure 1-11).
Downloaded from www.Manualslib.com
1
left cable-management
arm ramp assembly
on the opposite side of the rack from where you attached the cable-
management arm (see Figure 1-11).
Locate the ramp assembly wireform guide at the bend of the cable-
a
management arm.
Lift and slide the ramp assembly wireform guide up the ramp,
b
stopping at the ramp assembly seating catch.
If you have selected the correct ramp assembly, the wireform guide will
c
seat correctly in the catch at the top of the ramp assembly each time
the system is cycled in the rack. Figure 1-11 shows the left ramp
assembly installed with the cable-management arm attached on the
right.
manuals search engine
2
2 right cable-management
arm ramp assembly
Rack Installation Guide
3
3 metal ramp
23
