ENGLISH
290 mm
490 ±1
mm
55 mm
max.
R 5 mm
min. 28 mm
Important!
• For further information on the installation
refer to the Assembly Instruction.
• If there is no oven beneath the hob insert
a dividing panel at a minimum distance
of 20 mm from the bottom of the hob.
• Protect the cut surfaces of the worktop
against moisture using a suitable sealant

Electrical connection

Warning! Refer to Safety
chapters.
Warning! All electrical
connections must be made by an
authorised installer.
Electrical connection
• Before connecting, check that the
nominal voltage of the appliance stated
on the rating plate, corresponds to the
available supply voltage. Also, check the
power rating of the appliance and
ensure that the wire is suitably sized to
suit the appliance power rating (refer to
the "Technical information" chapter). The
min.
500 mm
520 mm
270 ±1
mm
min.
100 mm
included in the product in fitting bag. The
sealant seals the appliance to the
worktop with no gap.
• Do not use silicon sealant between the
appliance and the worktop.
rating plate is located on the lower
casing of the hob.
• The appliance is supplied with a
connection cable. This has to be
provided with a proper plug, able to
support the load marked on the
identification plate. To connect the plug
to the cable, follow the recommendation
given in following figure.
9
min.
28 mm
