GB
also observe the safety regulations, the assembly
instructions and the operating instructions to be found
in this manual.
All persons who use and service the equipment have
to be acquainted with this manual and must be
informed about the machine's potential hazards.
It is also imperative to observe the accident
prevention regulations in force in your area.
The same applies for the general rules of health and
safety at work.
The manufacturer will not be liable for any changes
made to the machine nor for any damage resulting
from such changes.
Even when the equipment is used as prescribed it is
still impossible to eliminate certain residual risk
factors. The following hazards may arise in
connection with the machine's construction and
design:
Harmful emissions of wood dust when used in
closed rooms.
Contact with the blade in the uncovered cutting
zone.
Injuries (cuts) when changing the blade.
Crushed fingers.
Kickback.
Tilting of the workpiece due to inadequate
support.
Touching the blade.
Catapulting of pieces of timber and workpieces.

4. Technical data

Mains voltage
Power
Operating mode
Idle speed n
0
Protection type
Stroke
Base area
Tilting range of table
Size of table
Length of saw blade
Max. cutting length at 90°
Max. cutting length at 45°
Weight
Wavelength of laser
Laser output
10
16.06.2011 9:27 Uhr Seite 10
Load factor:
A load factor of S2 5 min (intermittent periodic duty)
means that you may operate the motor continuously
at its nominal power level (120 W) for no longer than
the time stipulated on the specifications label (5
minutes ON period). If you fail to observe this time
limit the motor will overheat. During the OFF period
the motor will cool again to its starting temperature.

Noise emission values

The noise emission values were measured in
accordance with EN 61029.
Sound pressure level L
K uncertainty
pA
Sound power level L
K uncertainty
WA
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Keep the noise emissions and vibrations to a
minimum.
Only use appliances which are in perfect working
order.
Service and clean the appliance regularly.
Adapt your working style to suit the appliance.
Do not overload the appliance.
Have the appliance serviced whenever
necessary.
Switch the appliance off when it is not in use.
230 V ~ 50Hz
70/120 Watt
Residual risks
S1/S2 5 min Even if you use this electric power tool in
accordance with instructions, certain residual
400-1600 min -1
risks cannot be rules out. The following hazards
IP 20
may arise in connection with the equipment's
15 mm
construction and layout:
1. Lung damage if no suitable protective dust mask
470 x 190 mm
is used.
-45°/0°/45°
2. Damage to hearing if no suitable ear protection is
420 x 270 mm
used.
127 mm
50 mm

5. Before starting the equipment

20 mm
18 kg
5.1 Please note
650 nm
All covers and safety devices have to be properly
< 1 mW
fitted before the machine is switched on.
It must be possible for the blade to run freely.
When working with wood that has been
processed before, watch out for foreign bodies
Functions
82.6 dB(A)
pA
3 dB
92.4 dB(A)
WA
3 dB
