DATA I/O SCREEN (INPUT ASSIGNMENT SCREEN)
Item
TERMINAL Specifies the DATA I/O terminal number on which the
subsequent settings will be performed.
NOTES
●Each one of terminals 1 to 15 can be set when item I/O is
set to "16ALM IN".
●Each one of terminals 9 to 16 can be set when item I/O is
set to "8 ALM OUT/8ALM IN" or "8 SEL OUT/8 ALM IN".
CAMERA Sets the camera number corresponding to each DATA I/O
terminal.
IGNORE : No correspondence.
1 to 16
POSITION Sets the position number corresponding to each DATA I/O
terminal.
ALARM Sets the characters to be sent through the MONITOR
TEXT OUTPUT connectors in case of alarm.
POLARITY Sets the polarity of the alarm input.
MAKE
BREAK : Alarm signal is output at the break connection.
Function
: Set the camera number according to the terminal
number.
: Alarm signal is output at the make connection.
5. MENU SCREEN SETUPS
Options Default
1 to 16 1
(9 to 16) (9)
IGNORE, IGNORE
1 to 16
HOME, HOME
1 to 99
(NONE), alarm, (NONE)
ALARM, A,
TROUBLE, OPEN
DOOR,
WARNING, CALL,
ABNORMAL,
SENSOR,
INVADER,
(EDIT 1)–(EDIT 10)
MAKE, MAKE
BREAK
E-31
