5. Before starting the equipment

Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Always pull the power plug before making
adjustments to the equipment.
The lawn mower is delivered unassembled. The
complete push bar and the grass collector must
be assembled before using the lawn mower. Fol-
low the operating instructions step-by-step and
use the pictures provided as a visual guide to
easily assemble the machine.
5.1 Fitting the push bar (Fig. 3a to 3d)
Fit a bottom push bar (Fig. 3a / Item 8) into the
opening provided for it (Fig. 3a) and secure it as
shown in Fig. 3b with a screw (Fig. 3b / Item 9).
Proceed in the same way on the other side.
When you fi t the top push bar you can decide the
height of the push bar by selecting the appropri-
ate fastening hole (Fig. 3c). Fasten the top push
bar using either the holes L for a low position or H
for a high position. Screw the top push bar to the
bottom push bar as shown in Fig. 3d.
5.2 Fitting the grass box (Fig. 4a to 4d)
Fit the two halves of the grass box together (Fig.
4a / Item 12). The two halves are identical. Ensure
that all the plastic lugs engage correctly. Next
push the grass box handle (Fig. 4b / Item 13) into
the openings on the grass box.
Before you fi t the grass bag you must ensure that
the motor is switched off and the blade is not
rotating. The grass box must be attached to the
two hooks on the mower (Fig. 4c / Item A). To do
this, open the ejector fl ap with one hand (Fig. 4d
/ Item 5) and attach the grass box with the other
hand as shown in Fig. 4d. The ejector fl ap is held
against the grass box by a spring.
5.3 Setting the cutting heights
Important!
Adjust the cutting height only when the engine is
switched off and the power cable has been dis-
connected.
Before you begin to mow, check to ensure that the
blade is not blunt and that none of the fasteners
are damaged. To prevent any imbalance, replace
blunt and/or damaged blades. To carry out this
check, fi rst switch off the motor and pull out the
power plug.
Anl_GC_EM_1437_SPK1.indb 21 Anl_GC_EM_1437_SPK1.indb 21
GB
The cutting height is adjusted as shown in Figs.
5a and 5b. To do so, turn the equipment upside
down or tilt it to the side. Position both the front
and rear axle in the same notch, so that the cut-
ting blade runs parallel to the lawn.
Position Cutting depth
1 60 mm
2 42.5 mm
3 25 mm
Power supply
The lawn mower can be connected to any light
socket-outlet with a 230 Volt alternating current.
However, the socket outlet must have an earthing
contact protected by a 16 A circuit breaker. Addi-
tionally, a residual current device (RCD) circuit-
breaker with max. 30 mA must be used!
Power cable for the device
Please only use power cables that are not dama-
ged. The total length of the power cable should
not exceed 50 meters; going beyond this distance
will reduce the power output of the electric motor.
The power cable must have a cross-section of 3
x 1.5 mm. The insulating sheath of lawn aerator
power cables is frequently damaged.
Some of the causes for this are:
•
Cuts caused by driving over the cable.
•
Pinching when the power cable is dragged
under doors and pulled through windows.
•
Cracking due to old age of the insulation.
•
Kinking by improperly fastening or guiding the
power cable.
The power cables must, at the very minimum, be
of type HO5RN-F and 3-stranded. The cable type
must be printed somewhere on the power cable.
Only purchase power cables that are marked!
Plugs and socket couplers for the power cables
must be made from rubber and splash-proof.
There is a limit to how long power cables can be.
Longer power cables require larger conductor
cross-sections. Power cables and connecting li-
nes must be regularly checked for damage. Ensu-
re that the lines are switched off before checking
them. Completely unwind the power cable. Also
check power cable entry points, plugs and socket
couplers for kinks.
- 21 -
