SPECIFICATIONS
IF-C21SDG: SDI Input Card (Embedded Audio compatible, Auto Input
Type
Inputs/Outputs
Audio output
Format
Required slots
Power consumption : 14 V DC, 0.6 A
Weight
Dimensions
(W x H x D)
IF-C51SDG: SDI Input Card (Embedded Audio compatible, Auto Input
Type
Inputs/Outputs
Audio output
Format
Required slots
Power consumption : 14 V DC, 0.6 A
Weight
Dimensions
(W x H x D)
IF-C12HSDG: HD SDI Input Card
Type
Inputs/Outputs
Format
Required slots
Power consumption : 14 V DC, 0.6 A
Weight
Dimensions
(W x H x D)
4
function compatible)
: DT-V Series monitors
: 2 lines SD SDI signal input BNC x 2 (0.8 Vp-p, 75 Ω)
1 line SD SDI signal output BNC x 1 (0.8 Vp-p, 75 Ω)
* Reclock out
: 1 line (monaural LINE OUT)
(250 mV(rms), high impedance (–18dB))
: D1 serial component digital, 525/625 auto-switching
(SMPTE259M compatible)
SMPTE272M (Embedded Audio: 48 kHz, 1-8 channel compatible)
: 1
7 V DC, 0.6 A
: 0.5 kg
: 43 mm x 154.5 mm x 191.8 mm
* Auto Input function compatible
function compatible, Audio Level Meter compatible)
: DT-V Series monitors
: 2 lines SD SDI signal input BNC x 2 (0.8 Vp-p, 75 Ω)
1 line SD SDI signal output BNC x 1 (0.8 Vp-p, 75 Ω)
* Reclock out
: 1 line (monaural LINE OUT)
(250 mV(rms), high impedance (–18dB))
: D1 serial component digital, 525/625 auto-switching
(SMPTE259M compatible)
SMPTE272M (Embedded Audio: 48 kHz, 1-8 channel compatible)
: 1
7 V DC, 0.6 A
: 0.5 kg
: 43 mm x 154.5 mm x 191.8 mm
* Auto Input function compatible
* Audio Level Meter function compatible
: HD SDI input card for Multi-Format Monitor
: Digital input (HD SDI 1/HD SDI 2):
2 lines, BNC connector x 2 (0.8 Vp-p, 75 Ω)
(compliant with AES/EBU EMBEDDED AUDIO)
Digital output (HD SDI 1/HD SDI 2):
2 lines, BNC connector x 2 (0.8 Vp-p, 75 Ω)
: BTA S-004B, SMPTE292M (digital interface standard)
BTA S-006B, SMPTE299M (Embedded Audio: 48 kHz, 1-8
channel compatible)
: 1
7 V DC, 0.6 A
: 0.5 kg
: 43 mm x 154.5 mm x 191.8 mm
(continued)
RCA pin connector x 1
RCA pin connector x 1
SWITCHED
OUT
IN1
E.AUDIO
SDI
IN2
AUDIO
MONITOR
OUT
with LEVEL METER
SWITCHED
OUT
IN1
E.AUDIO
SDI
IN2
AUDIO
MONITOR
OUT
E.AUDIO
HD SDI 1
IN
OUT
E.AUDIO
HD SDI 2
IN
OUT
