Indicator lamp
White Permanent light
(has 3 mean-
ings)
Blinks slowly
Fast flashing
Red Battery charge below 15 %
Operation after a long rest period or after a depleted
battery
If the cleaning robot is turned on with completely empty
batteries, the appliance is not operative. Perform the fol-
lowing steps to put the appliance into operation:
 Switch the cleaning robot on using the power
switch.
 Push the cleaning robot carefully onto the charging
station.
Functions of AUTO button
Starting cleaning
 Push the AUTO button if the cleaning robot is in
standby.
The cleaning robot starts the cleaning run.
Charge mode
 Press and hold down the AUTO button for two sec-
onds if the robot is in standby mode outside of the
station
The cleaning robot switches to charging mode and
returns to the station.
Note: During cleaning, the cleaning robot automat-
ically returns to the station if the battery is low.
Stopping the cleaning robot
 Push the AUTO button to stop the current action by
the cleaning robot.
The cleaning robot switches to standby.
Note: If no action has been performed in standby
after 3 minutes, the robot will switch to idle mode
and the indicator light will go out.
Waking up the cleaning robot
 Push the AUTO button to wake up the cleaning ro-
bot from idle mode.
Operating modes
The cleaning robot has two operating programs.
Operating Programmes of the cleaning robot
1 Automatic mode
Normal cleaning
The robot cleans all reachable areas of the home
and traverses these systematically.
2 Spot cleaning mode
Precise cleaning of an area selected by the cus-
tomer (a 1.5 m square).
18
– During the cleaning
run
– When finished charg-
ing process
– When in standby sta-
tus, lights up for 3 min-
utes, then turns off
Charging process
Switch-on process
Terminate operation / switch off
If the cleaning robot has immediately to finish the clean-
ing work, or the appliance has to be used in a different
location.
 Push the AUTO button.
 Switch the cleaning robot off using the power
switch.
Note: If the cleaning robot is not used for a longer peri-
od of time, recharge the battery fully beforehand (see
"Commissioning" section).
Remove the charged battery (See "Removing battery"
Chapter) and store it in a cool, dry place.

Maintenance and care

DANGER
Turn off the station and the cleaning robot before per-
forming any maintenance work!
Cleaning the wheels
 Clean the running surfaces of the wheels when
these become dirty.
Dirt particles (such as sand, etc.) can collect on the
running surface and damage sensitive, smooth
floor surfaces.
Cleaning the dirt receptacle
Illustration
 Push the bar on the dirt receptacle down and pull it
out.
Illustration
 Push the bars up on both sides of the dirt recepta-
cle.
Illustration
 Open the flap of the dirt receptacle.
 Dispose of the dirt and clean the dirt receptacle
with the brush.
Cleaning the filter
 Remove the dirt receptacle (see previous descrip-
tion).
Illustration
 Push the unlocking button on the blower.
The blower pops out.
Illustration
 Remove the filter.
 Clean the filter by using the supplied brush.
Removing/cleaning the cleaning roller
 Removing the cleaning roller
Illustration
 Press the locking lug on the cleaning roller support
in the direction of the arrow.
Fold open the support and protective grille.
 First remove the rubber brush and then the roller
brush.
Illustration
 Cut threads and hairs with a pair of scissors.
 Remove any threads and hairs that have become
caught.
 Cleaning the cleaning roller
 Clean the cleaning roller regularly with the brush.
– 10
